With the monitor, wireless video receiver and remote control integrated in one device, MasterEye Visual Controller VC100 is gifted at performance and compatibility. Ergonomically-designed handgrip, snug silicone for better quality, simplified installation and connection, as well as auto pairing, all features contribute to your filmmaking in the wake of teamwork efficiency.

Larger Storage Support

The MasterEye Visual Controller supports Micro SD card to max 128GB capacity with write speed exceeding 10MB/s, transfer speed of Class 10 and above or microSD card with UHS-1 rating.

Offers 1080P high-quality recording backups and local album playback. Offers 3.5mm headphone port for real-time audio monitoring in scenes with conversations and audio ( this feature can only be achieved when using with transmitter 2.0, transmitter AI doesn't support this ).

Product Specifications

Rated Power	3W
Rated Voltage	11.1V
Charging Voltage (Type-C Port)	4.9V~20V
Charging Current (Type-C Port)	20mA~3A
Internal Battery Runtime	8hr
Internal Battery Charging Time	110min
Internal Battery Capacity	2200mAh
External Battery Input Voltage	6V~8.4V
Output Resolution	1080P/720P/576P/480P
Output Frame Rate	60/59.94/50/30/29.97/25/24/23.98fps
Image Transmission Latency	60ms
Operation Frequency	5.725GHz-5.825GHz
	5.15GHz-5.25GHz（For Japan)
Equivalent Isotropically Radiated Power (EIRP)	5.15GHZ-5.25GHZ <23DBM（CE）
	5.725GHZ-5.825GHZ <14DBM（CE）
	5.15GHZ-5.25GHZ <24DBM（FCC）
	5.725GHZ-5.825GHZ <30DBM（FCC）
	5.15GHZ-5.25GHZ <23DBM（SRRC）
	5.725GHZ-5.825GHZ <27DBM（SRRC）
Transmission Distance	150 meters
Antenna Rotation Angle	0° ~90°
Screen Dimensions	5.5 inch
Screen Resolution	1920*1080
Screen Aspect Ratio	16:9
Screen Brightness	1000 nits
Recording Resolution/Frame	Current Resolution/Frame Rate of the Image Transmission
Screen Viewing Angle	80°
Supported Micro SD Card Types	Max 128 GB storage, write speed ≥10MB/s, transfer speed of Class 10 and above or microSD card with UHS-1 rating
Supporting File System	FAT32
Operating Temperature	-10℃ ~45℃
Product Net Weight	~450g
Dimensions with Expanded Antenna	20372154mm (LWH)
Dimensions with Folded Antenna	2037292mm (LWH)

What's in the Box

ZHIYUN MasterEye Visual Controller VC100 * 1

USB Type-C cable * 1

User Manual * 1

Immerse Yourself in Vivid Footage

Transform Filmmaking Works into A Hub of Productivity

Always Stay Bright and Vivid

Larger Storage Support

Screen Recording & Audio Monitoring

Accurate Focus/Zoom Control and Motion Sensor Control

Product Specifications

What's in the Box
